China 7 inch 1024×600 1000nit RGB IPS TFT LCD Display with CTP Manufacturer, Suppliers

H070IWS50I1K002-CT24 is a 7-inch TFT LCD Display with high brightness, wide operating temperature range, and capacitive touch function. This LCD screen has a wide operating temperature range, capable of withstanding -30℃ to +85℃, meeting the stability operation requirements in extreme climate conditions. It adopts IPS full-view technology, with a visual angle of 178°, accurate color reproduction; it supports anti-glare (AG), anti-reflection (AR), and full-lamination (OCA) processes, enhancing outdoor visibility and durability. The resolution is 1024×600, with an RGB 50-pin interface, HX8282/HX8696 Driver IC, supporting 5-point or 10-point touch, with sensitive response and smooth operation, and supporting glove or wet-hand operation (some models have AG/AR surface treatment). The 1000nit high brightness ensures that the screen remains clear and readable even in direct sunlight. This 7-inch TFT LCD module is mainly used in industrial control and HMI terminals: for PLC controllers, CNC machines, data acquisition systems, etc., in human-computer interaction interfaces, supporting wide temperature, shock resistance, and dust-proof design, ensuring stable operation 7×24 hours. Vehicle electronic systems: as the core of vehicle central control, rearview camera, dashboard display, the 7-inch size is appropriate, combined with high brightness and wide temperature characteristics, it adapts to the complex environment of large temperature differences between day and night and strong light exposure in the vehicle. Charging piles and outdoor self-service equipment: in highway service areas and urban public charging stations, the high-brightness screen (≥1000nits) can ensure clear display of charging status and payment information under strong sunlight, combined with capacitive touch to enhance user experience. Medical and portable detection equipment: applied to portable monitors, handheld ultrasound, on-site detection instruments, etc., high-definition display helps data interpretation, low-power design extends battery life. Some models have passed medical-grade certification, supporting disinfection cleaning and long-term stable operation. Smart home and security systems: used for intelligent control panels, visual access control, security monitoring terminals, supporting multi-point touch and remote linkage, enhancing the intelligent experience of home and commercial spaces.
